TommaTech Trio Atom K 10.0kW Three Phase Inverter

TommaTech Trio Atom K 10.0kW Three Phase Inverter

TommaTech Inverters
Ask Price

With the latest Trio Atom K Series inverters, TommaTech continues to set new standards in the residential solar market. Equipped with two high efficiency MPPTs ranging from 3kW to 15kW, TommaTech new three-phase on-grid inverters maximize solar energy use with their extraordinarily high maximum PV input capacities.

Maximum PV Array Power (Wp)
20000
Maximum DC Voltage (V)
1000
Rated DC Operating Voltage (V)
640
Maximum Input Current (A)
16/16
Maximum Short Circuit Current (A)
20/20
MPPT Voltage Range (V)
120-980
Switching Voltage (V)
150
Number of MPPTs
2
MPPT Array Input Number
1/1
Rated AC Power (VA)
10000
Nominal Mains Voltage (AC Voltage Range)
220/380, 230/400, 3/N/PE, 3/PE
Nominal Mains Frequency (Hz)
50/60;±5
Rated AC Current (A)
15.2/14.5
Maximum AC Current (A)
16.0
Displacement Power Factor
0.8 Ahead ~ 0.8 Behind
Total Harmonic Distortion (Thdi), Rated Power (%)
3
European Efficiency (%)
97.8
Maximum Efficiency (%)
98.3
Standby Mode Consumption (Night) (W)
<3
High Voltage Protection
Yes
High Current Protection
Yes
DC Isolation Impedance Monitoring
Yes
Ground Current Fault Monitoring
Yes
DC Current Injection Monitoring
Yes
Residual Current Relay Protection
Yes
Security
IEC62109-1/-2
Electromagnetic Compatibility (EMC)
EN61000-6-1;EN61000-6-2;EN61000-6-3;EN61000-3-2;EN61000-3-3
Protection Class (According to IEC60529)
IP66
Operating Temperature Range [°C]
-30~+60 (Low Yield>45)
Maximum Working Height (m)
<4000
Humidity (%)
0~100 (Condensing)
Noise Emission (Db)
<45
Dimensions (Width X Height X Depth)
342x434x156
Cooling Method
Akıllı Hava Soğutma
Communication Interface
RS485 / DRM / USB - Update / Optional: Dongle Wi-Fi / Dongle LAN / Remote Wi-Fi / Smart Meter
Cooling Method
Intelligent Air Cooling
Weight (kg)
17
5 (Extendable)
Storage Temperature [°C]
-30~+60
Maximum AC Power [VA]
11000
TRIO ATOM K Dual MPPT
Show Download
TommaTech Trio Atom K Series Certification
Show Download
TommaTech Trio Atom K Series IEC61727 Certification
Show Download
TommaTech Trio Atom K Series VDE Certificate
Show Download
TommaTech Trio Atom K Series EN50549 Certificate
Show Download
TommaTech Trio Atom K-Series LVD Certificate
Show Download
TommaTech Trio Atom K-Series TOR Certificate
Show Download
Trio-Atom K-Series EMC Certificate
Show Download
TOMMATECH INVERTER CE - 2
Show Download
TommaTech Inverter Warranty Document
Show Download
TommaTech Trio Atom K Series User Manual
Show Download
TommaTech Trio Atom Quick Installation Guide
